| Weight | 4.1kg |
| Size | 200mm×200mm×268mm（L×W×H） |
| Size of Sample Room | 170mm×130mm×60mm（L×W×H） |
| Excitation source | Up to 50kV, 200uA X-ray tube, upper excitation power 4W, Ag/Rh target |
| Detector | BOOST Si-pin/SDD(Optional) |
| Operation System | Based on the I. MX 6 Quad， quad-core Cortex-A9 processor
Dedicated analytics operating system, 32GB of system memory |
| Data Processing | Built-in 32GB storage
USB, can connect the device to the Internet, remote setting and maintenance of the instrument |
| Target | W/Ag/Rh(Optional) |
| Resolution | <136eV |
| Data Transfer | USB, Bluetooth |
| Operating Ambient Temperature | -20℃~50℃ |
| Operating Ambient Humidity | 10%~90% relative humidity, non-condensing |
| Display | 5.7-inch absorbable color touch screen display |
| Test Time | User customize |
| Optional | Built-in 5 million pixel high-definition camera |
| Language | Chinese, English, etc. |
| Air mode | Air mode, helium mode, vacuum mode (optional) |
